Amateur Radio de W9AEK
One of the hobbies I enjoy the most is amateur radio (AKA "Ham Radio").
There are many facets to amateur radio and here are the things I enjoy
the most about the hobby:
- Modifying Motorola commercial radio gear for use on the Ham bands
- Fast Scan TV
- Radio Teletype - Modifications and repair of model 28 KSR's
I am the Illinois Ham TCP/IP address coordinator. If you are an Illinois
ham and need a TCP/IP address, just send me e-mail,
ken at svs dot com
and I will return your IP address as soon as I can. If you are in the Chicago
area and need a TCP/IP address, I will need the frequency and the router(s)
that you will use. If you are outside Chicago area, I will need your ZIP code
and frequency.
I have been licensed as WA9AEK from 03/1961 to 08/2013 when I applied for the
vanity call sign of W9AEK.
W9AEK 1.2Ghz Voice Repeater (Lisle, IL) In full operation.
Output: 1293.100Mhz Input: 1273.100Mhz
Features:
- Tower Coordinates: 41-46-20.4N 088-04-24.0W
- Tower Height (AGL): 307.08ft
- Tower Ground Elevation (AMSL): 664.04ft
- Antenna Height (AGL): 290ft
- Autopatch (closed)
- Effective Radiated Power (ERP): 158.4893W
- Emergency power source
- Long Tone Zero (LiTZ) Emergency Alert System
- Open access - 114.8 pl
- Remote base operation on 144, 220, 420Mhz, and 1.2Ghz
- Reverse autopatch (closed)
- Temperature and wind speed indications at 15 and 45 minutes past the hour
- Weather alerts direct from the National Weather Service
W9AEK 442.700Mhz Voice Repeater (Lisle, IL) Will be converted to W9KHS D-Star around Jul 2021
Output: 442.700Mhz Input: 447.700Mhz
Features:
- Antenna Height (AGL): 280ft
- Autopatch (closed)
- Effective Radiated Power (ERP): 54.01W
- Emergency power source
- Long Tone Zero (LiTZ) Emergency Alert System
- Open access - 203.5 pl
- Remote base operation on 144, 220, 420Mhz, and 1.2Ghz
- Reverse autopatch (closed)
- Temperature and wind speed indications at 15 and 45 minutes past the hour
- Weather alerts direct from the National Weather Service
W9AEK 224.620Mhz Voice Repeater (Lisle, IL) down for antenna repair
Output: 224.620Mhz Input: 223.020Mhz
Features:
- Antenna Height (AGL): 270ft
- Autopatch (closed)
- Effective Radiated Power (ERP): 38.779W
- Emergency power source
- Long Tone Zero (LiTZ) Emergency Alert System
- Open access - 110.9 pl
- Remote base operation on 144, 220, 420Mhz, and 1.2Ghz
- Reverse autopatch (closed)
- Temperature and wind speed indications at 15 and 45 minutes past the hour
- Weather alerts direct from the National Weather Service
W9AEK ATV Repeater (Lisle, IL) Planning Stages
Output: to be assigned Input: 439.250Mhz
Features:
- Antenna Height (AMSL):
- Effective Radiated Power (ERP):
- Emergency power source
W9SRO Voice (CFAR & TWOFAR) Repeater (Chicago, IL)
- I am on the technical crew and active on the CFAR (147.150 +0.600, 107.2pl)
and TWOFAR (224.860 -1.600, 107.2pl) repeaters.
W9JEM Repeater - Lake Zurich, IL Output 927.6875, Input 902.6785 151.4 PL
I also operate SSB and CW on 80-2 meters, 70 & 23cm, AM on 40 meters, FM on 10 meters
thru 23cm. Every now and then, I will dabble with fast scan analog ATV.
And active on auto-start RTTY 145.000 using Teletype model 28 KSR, homebrew TU & ST-6,
& LRXB tape unit. Also use a Teletype model 14.
Ken Stritzel, W9AEK ken at svs dot com
May 14, 2020 18:25
